Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology

Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology

Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology
Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology

Μεγάλες Εικόνας :  Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology

Λεπτομέρειες:
Τόπος καταγωγής: Ιαπωνία
Αριθμό μοντέλου: ΚΕ-50
Πληρωμής & Αποστολής Όροι:
Ποσότητα παραγγελίας min: 1pcs
Τιμή: Διαπραγματεύσιμα
Συσκευασία λεπτομέρειες: Τυπική Συσκευασία
Χρόνος παράδοσης: 5-8 εργάσιμες ημέρες
Όροι πληρωμής: Δ/Κ, D/Α, D/P, T/T, Western Union, MoneyGram
Δυνατότητα προσφοράς: 5000 τεμάχια

Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology

περιγραφή
Εύρος μέτρησης: 0 - 100% οξυγόνο Ακρίβεια: ±2% (ολικής κλίμακας)
Περιοχή θερμοκρασίας λειτουργίας: 5 - 40°C Πεδίο θερμοκρασίας αποθήκευσης: - 20 - 60°C
Σειρά σχετικής υγρασίας: 10 - 90% RH Ατμοσφαιρική σειρά πίεσης: 811 - 1216 hPa
Επισημαίνω:

medical oxygen gas sensor

,

long life oxygen sensor

,

electrochemical oxygen sensor biotechnology



                           Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology



Product Features:

  • Long Life: With an expected service life of up to 10 years, it can provide stable performance over an extended period.
  • Good Chemical Stability: Hardly affected by common gases such as CO₂, CO, H₂S, NOₓ, and H₂, ensuring high - accuracy oxygen measurement.
  • Low Cost: Has cost - effectiveness, suitable for a variety of applications.
  • Operates in Normal Ambient Temperatures: Can work normally in the temperature range of 5 - 40°C without the need for additional temperature - control equipment.
  • Stable Output Signal: Can provide a relatively stable output signal for accurate oxygen concentration detection.
  • No External Power Supply Required: Simplifies the installation and use process, and can be used in various portable or fixed - installed detection devices.
  • No Warm - up Time Required: Can quickly start working and provide detection results without pre - heating, improving work efficiency.

Applications:

  • Medical Field: Used in medical anesthetic instruments, respirators, and oxygen - enrichers to monitor oxygen concentration and ensure the safety and effectiveness of medical treatment.
  • Biotechnology: Applied in oxygen incubators to maintain the appropriate oxygen environment for biological experiments and cell culture.
  • Food Industry: Used in food refrigeration to control the oxygen content and prolong the shelf - life of food. Also used in greenhouses to optimize the growth environment of plants.
  • Safety Field: Installed in oxygen detectors and fire detectors to ensure the safety of the environment. It can also be used in air - conditioners to monitor and adjust the oxygen content in the air.



Measuring Range 0 - 100%
Accuracy ±2% (full - scale)
Operating Temperature Range 5 - 40°C
Storage Temperature Range - 20 - 60°C
Relative Humidity Range 10 - 90% RH (non - condensing)
Atmospheric Pressure Range 811 hPa - 1216 hPa
Response Time 60 ± 5 s
Initial Output Voltage under Standard Test Conditions 47.0 - 65.0 mV
Offset Voltage ≤ 6.0 mV
Linearity ((VA - V0)/(V100 - V0)) 0.21 ± 0.02
Characteristics (VH/VA, VL/VA) 0.91 - 1.09
Dimensions φ28 × 47.3 mm
Weight Approximately 24 g
Life Expectancy 10 years



Gas Oxygen Sensor KE-50 Long Life Electrochemical Oxygen Sensor for Medical Field Biotechnology 0
