YJJ SCC30ASMT Board Interface Pressure Sensor 0 To 30 Psi For Industrial Automation Applications

Product Description:

SCC30ASMT Board Interface Pressure Sensor 0 To 30 Psi For Industrial Automation Applications

Features:

SCC30ASMT is a piezoresistive pressure sensor, mainly used for measuring absolute pressure (i.e., the pressure of the medium relative to vacuum).

Its key features include:

Surface Mount Technology (SMT process)

Measurement range: 0 - 30 psi

Uses piezoresistive technology (pressure detection is achieved through the deformation of a silicon diaphragm and the resulting change in resistance)

Response time: only 100 microseconds Typical application scenarios

Industrial Automation: Suitable for hydraulic/pressure control systems that require rapid response, such as pressure monitoring modules in automated equipment.

Electronic devices: May be used for internal pressure detection in electronic devices, such as the pressure sensor components found in consumer electronics.

Automotive industry: It can monitor parameters such as engine lubricating oil pressure and fuel system pressure.

The specific application depends on the actual product parameters:

Pressure Type: Gauge, Differential

Working Pressure: 0 psi to 30 psi

Accuracy: 1%

Output Type: Analog

Installation Style: SMD/SMT

Port Type: No Port

Minimum Operating Temperature: -40°C

Maximum Operating Temperature: +125°C

Series: SCC SMT

Working Power Supply Current: 1.5 mA

Port Size: 2.3 mm

Product Type: Board Mount Pressure Sensors 5

Subcategory: Sensors

Specifications:
